IPS
D8-IPS 800
Technical Data
Rated rpm |
3000 |
|---|---|
Crankshaft Power, HP / kW |
600 hp / 441 kW |
Rating |
5 |
Bore / Stroke (mm) | 110 / 135 |
Displacement (L) | 7.7 |
Dry Weight Bobtail with Drive (kg) | 1410 |
Emission Compliance |
EPA Tier 3, EU RCD Stage II, IMO NOx Tier II |
Number of Cylinders |
6 |
Aspiration |
Twin entry turbo and compressor with charge air cooler |
High-pressure Fuel Injection |
Common-rail fuel injection |
Control System |
Electronic Vessel Control |
Fuel Consumption, at 100% load (L/H) |
119 |
Speed Range | 20 to 40 knots |
